光電雷射測定儀
- 首頁
- >
- 工廠設備
- >
- 工廠設備
| Model | LMG1505-P |
| Type | P Type |
| Measurement Scope | 0.7~150mm |
| Minimum measure unit | 0.1um |
| To & For Precision | ±0.5um |
| Sum Precision | ±0.4um |
| Abgular secto | ±0.6um |
| Scan Frequency | 1800 times/sec |
| Station Travel Distance | 500mm |
| Station Power | AC , Motor Driving, Steady speed rolling |
| Station Moving | Manually |
| Output Interface | RS-232C |
| Sampling | TIMER |
| Sampling Measurement Output | Calculate the max, min, R, abgular sector dimension |
| Power Supply | 85~250V±10% 50/60HZ |
